LPC-140G4 i3
* Product images are for illustration purposes only and may not be an exact representation of the item
LPC-140G4 Little PC – Compact Power for Demanding Industrial & Embedded Applications
A rugged, ultra-small form-factor computer engineered for reliability, performance, and seamless integration. Designed to deliver desktop-class capability in tight spaces, the LPC-140G4 is ideal for mission-critical environments.
Key Features & Customer Benefits
- Intel® Core™ i3 Performance for Reliable Processing.
- Extensive I/O Connectivity Including 4× Gigabit LAN & Dual Serial Ports.
- Expandable Mini-PCIe Architecture with High-Speed SSD & Memory.
- Dual Display Support via DVI-D & DisplayPort.
- Rugged Ultra-Compact Aluminum Chassis with Wide 10–26VDC Input
Typical Applications: industrial automation, machine control, IoT gateways, digital signage, test & measurement systems, and other embedded or space-restricted computing environments.
[{"System":{"Processors":["Intel® 4th Generation Core™ i3 Processor 4010U"],"Chipset":"","Memory":["2x DDR3 SO-Dimm memory slots providing options up to 16GB of RAM"],"Hardware Monitor":["Cooling fan speed","Processor temperature","Voltage"],"Key Switch":[],"Cable":[],"TPM Module":""}},{"Display":{"Display":[],"Aspect Ratio":"","Contrast Ratio":[],"Frequency":[],"Native Resolution":"","Response Time":"","Pixel Pitch":"","Controls":[],"Touchscreen":"","Video":["Dual Display support (clone or extended desktop)","Integrated Intel HD Graphics"]}},{"Storage":{"Internal Storage":["480GB 3D NAND SSD (Solid State Drive) standard (SATA)"],"Drive Bays":[],"Removable Storage":[],"Optical Drives":[]}},{"Input / Output":{"Ports":[],"Video Input":[],"Networking":["1x Integrated 10/100/1000 Base-T Intel (i218LM) Gigabit Ethernet controller, RJ45 connection (PXE support)","3x Integrated 10/100/1000 Base-T Intel (i210-AT) Gigabit Ethernet controller, RJ45 connection (PXE support)","Optional 802.11 b/g/n/ac Dual Band (2.4Ghz / 5Ghz) Wireless Networking and Bluetooth 4.0, Realtek® RTL8821AE via internal Mini-PCIe"],"Communications":[],"Audio":["Integrated Realtek® High Definition Audio CODEC ALC892"]}},{"Expansion":{"Internal Expansion":[],"Expansion Slots":[]}},{"Operating Systems":{"Operating Systems":["Please contact us directly for any special requirements","Ubuntu Linux","Windows 10 (64-bit)"]}},{"Power":{"Power":["ACPI compliant and Operating System direct power management","Includes External AC Adapter, Input 100-240V AC @ 1.5A 50-60Hz","Input: 10-26V DC","Rear 12V DC power Jack ideal for mobile applications","Wake-on event"]}},{"Environmental":{"Environmental":["Operatin Relative Humidity: 10% - 80%, non-condensing","Operating Temperature: 0C – +40C (+32F – +104F)","Storage Humidity: 0% - 90%, non-condensing","Storage Temperature: -20C – +60C (-4F – +140F)"]}},{"Compliance":{"Approvals":[],"Compliance Certification":[]}},{"Physical":{"Chassis Description":["Includes Panel/Wall Mount Brackets","Low Profile Rugged Aluminum Chassis"],"Housing":[],"Bezel Type":[],"Front Panel":["2x RS232 COM ports","3x USB 2.0 Ports","4 x 10/100/1000 RJ45 Network connections","Headphone/Audio Line-Out Jack","Microphone Input Jack","Power and Hard Drive notification LED","Power-on button"],"Rear Panel":["1x DisplayPort video connector","1x DVI-D video connector","2x PS/2 ports for Keyboard & Mouse","2x USB 3.0 Ports","DC Power Input Jack"],"Cooling Fans":[],"Mounting":[],"Built-in Keyboard/Mouse":[],"Keyboard":"","Backlighting Illuminati":[],"Compliance-Certification":[],"Dimensions":["(W-D-H) 4.0\" x 6.1\" x 1.5\" (102mm x 155mm x 37.8mm)"],"Weight":["Power Supply Weight: 1.35 lbs (0.62kg)","Unit Weight: 1.5 lbs (0.58 kg), depending on configuration"]}},{"General":{"Compatibility":[],"Included with System":["100-240V AC Adapter","4x Rubber Feet","North American Power Cord","Wall Mount Bracket"],"Options":["802.11 a/b/g/n/ac Dual Band Wireless (2.4Ghz / 5Ghz) +Bluetooth 5.0 via M.2","Remote power option Ideal for OEM or Cabinet manufacturers","Removable Computer Module on LCD Monitor","Solid State Drives (SSD) SATA"],"WatchDog Timer":[],"Warranty":["6 Months Parts & Labor"],"Disclaimer":"Note: Specifications are subject to change without notice."}}]
